Electrifying Innovation: Mitsubishi Electric's New S1-Series HVIGBT Modules




In the bustling heart of Tokyo, an exciting announcement has just been made by Mitsubishi Electric Corporation. They are set to begin shipping samples of their revolutionary new S1-Series High Voltage Insulated Gate Bipolar Transistor (HVIGBT) modules. These cutting-edge modules, rated at 1.7kV, are poised to reshape the landscape for large industrial equipment, especially in railcars and DC power transmitters. With shipping starting on December 26, the anticipation is palpable.

The introduction of these HVIGBT modules is much more than just another product release. It's a testament to Mitsubishi Electric's commitment to innovation and reliability. Their proprietary Insulated Gate Bipolar Transistor (IGBT) devices, coupled with unique insulation structures, offer unparalleled reliability. Moreover, they promise low power loss and thermal resistance, elevating the efficiency and reliability of inverters in large-scale industrial equipment.



Mitsubishi Electric's 1.7kV HVIGBT modules have been a cornerstone in power systems since their first release back in 1997. Their excellent performance and high reliability have made them a preferred choice across the globe. The new S1-Series modules are a natural evolution of this legacy, incorporating advanced technologies that further enhance their capabilities.

One of the standout features of the S1-Series is the incorporation of Mitsubishi Electric's proprietary Relaxed Field of Cathode (RFC) diode. This innovation increases the Reverse Recovery Safe Operating Area (RRSOA) by an impressive 2.2 times compared to previous models, significantly boosting inverter reliability. Such advancements are critical, especially in an era where industrial equipment demands are ever-increasing.



At the heart of these modules is the IGBT element, featuring a Carrier Stored Trench Gate Bipolar Transistor (CSTBT) structure. This structure is pivotal in reducing both power loss and thermal resistance, ensuring that inverters operate more efficiently. Such efficiency is not just a nice-to-have; it's a necessity in today's fast-paced industrial environments.

Moreover, Mitsubishi Electric's proprietary insulation structure is a game-changer. It increases the insulation voltage resistance to 6.0kVrms, a staggering 1.5 times more than previous products. This enhancement allows for more flexible insulation designs, making these modules compatible with a broader range of inverter types. It's about more than just meeting current needs; it's about anticipating future demands and being ready for them.



The innovations embedded within the S1-Series HVIGBT modules aren't just technical marvels; they are strategic advantages that set Mitsubishi Electric apart in the competitive landscape. These modules are not only about technological advancements but are also a reflection of Mitsubishi Electric's vision to provide solutions that drive sustainability and efficiency.

As industries evolve and the demand for more robust and efficient power systems grows, the role of advanced technologies like Mitsubishi Electric's HVIGBT modules becomes increasingly vital. They are not merely components; they are enablers of progress, supporting industries in achieving greater heights of innovation and operational excellence.

In conclusion, the release of Mitsubishi Electric's S1-Series HVIGBT modules marks a significant milestone in the world of industrial equipment. It's an exciting development that promises to enhance the performance and reliability of systems worldwide. As we look to the future, it's clear that these modules will play a crucial role in powering progress, with Tokyo once again serving as the launchpad for groundbreaking innovation.
